Special single colour LED Strip Lights
- Qualified 2835LED
- Dedicated fresh food/jewelry lighting
- Dedicated haute color strip lighting
- 120 LEDs/M, 196 LEDs/M
- >90 CRI, <5 SDCM
- Up to 50000hours Lifespan
- 5 years warranty
Specifications:
Myledy specialized spectrum LED strip lights use a patented color formula, maintain their efficiency longer, consume less energy, and are best used in meat, fish, deli, bakery, dairy, fruits, and jewelry departments where extraordinary color presentation is critical.
Reduce Product Shrink
Specialized lighting reduces spoilage and photo-oxidation in foods, helping to preserve their quality and freshness for longer periods.
Accurate Color Rendering
Myledy enhances the vibrant and natural colors of products, presenting them in their most authentic performace.
Fresh food / jewelry lighting
Item No.: LD-2835H-24-192S10-14P0-C
- High-quality 2835 SMD
- 192 leds/m
- Lumens: 14.4W/m
- Power: 24V DC
- PCB Width: 10mm
- Cutting Length: 41.7mm
- IP grade: IP20 / IP62 / IP65 / IP67 / IP78
Dimension
Cake/Cheese LED strip light
Prcp WL: Ld=588nm; Peak WL: Lp=627nm
Fruit LED strip light
Prcp WL: Ld=584nm; Peak WL: Lp=623nm
fresh meet LED Strip light
Prcp WL: Ld=603 ; Peak WL: Lp=630nm
jadeite LED strip light
Prcp WL: Ld=581; Peak WL: Lp=457nm
golden LED strip light
Prcp WL: Ld=590; Peak WL: Lp=634nm
Seafood LED strip light
Prcp WL: Ld=580nm; Peak WL: Lp=456nm
Pickled ham LED Strip Light
Prcp WL: Ld=494nm; Peak WL: Lp=452nm
cosmetic LED strip light
Prcp WL: Ld=579nm ; Peak WL: Lp=456nm
diamond LED strip light
Prcp WL: Ld=480nm ; Peak WL: Lp=455nm
crystal LED strip light
Prcp WL: Ld=579 ; Peak WL: Lp=456nm
Haute Color Strip Lighting
Item No.: LD-2835L-24-120S08-10P0-C
- High-quality 2835 SMD
- 120 leds/m
- Lumens: 9.6W/m
- Power: 24V DC
- PCB Width: 8 mm
- Cutting Length: 50mm
- IP grade: IP20 / IP62 / IP65 / IP67 / IP78
Demension
golden light
Prcp WL: Ld=590nm; Peak WL: Lp=594nm
tomato led strip light
Prcp WL: Ld=608nm; Peak WL: Lp=613nm
rose-red LED strip light
Prcp WL: Ld=553nm; Peak WL: Lp=451nm
pink LED strip light
Prcp WL: Ld=501nm; Peak WL: Lp=451nm
ice-blue LED strip light
Prcp WL: Ld=489nm; Peak WL: Lp=493nm
violet LED strip light
Prcp WL: Ld=440nm; Peak WL: Lp=451nm
Myledy IP Grade Introduction:
IP is an acronym “Ingress Protection”, a measurement standard ratings used to indicate the level of protection for electrical equipment against solids and liquids.
Myledy is equipped with state of the art manufacturing equipment utilizing cutting edge technology and top quality silicone glue to offer anti-yellowing, resistance to high and low temperature and diverse IP rating lever IP62~IP68 waterproofing for special applications.
IP20
Non-Waterproof
IP62
Silicon Glue
IP65
Silicon Sleeve
IP66
Silicon Extrusion
IP67
Silicon Glue with
Half Sleeve
IP68
Silicon Glue With
Full Sleeve
Regular Wiring Method:
First, Calculate The Wattage of Each LED Strip — You should already have an idea of how much power will be required to run your LED light tapes. However, there might be some additions or subtractions in the number after you’ve cut and connected the tapes together. So, calculate the overall wattage required to power your flexible LED light strips again.
Second, Find Compatible Power Supply — You need to choose a driver that will use only 80% of its overall power to run the LED tapes. This is very important for the longevity of both your power supply and LED strips.
Third, Connect LED Strip to Power Supply — You can make series circuit or parallel circuit for the LED strip lights. And all Myledy LED strip lights are dimmable, you can also connect a dimmer for better brightness control.
